Deeper Start Fishfinder
Deeper Start Fishfinder
TAX NOTICE: UK prices include Tax. Tax is removed automatically for all other countries, however you may be subject to import duties.
SKU:DEEP06
Low stock: 1 left
Find the fish
Instantly locate fish just by casting. The 120 kHz, 40° sonar scans at 10 times per second, so you can cover wide areas and never miss a fish.
Know fish size and depth
Every fish icon tagged with size and depth data. Now choosing the right lure and rig is easy.
Scan deeper
The START’s powerful sonar scans down to 165 ft. / 50 m and shows bottom contour in detail.
Great casting range
The START’s Wi-Fi connection gives faster data transfer and rock solid connectivity up to 165 ft. / 50 m, so you’ll never miss a spot.
For anglers, Deeper means powerful and accurate, and the Deeper START is no exception. It has a huge casting range of 165ft / 50m and a scanning depth of 165ft / 50m. And it’s a fish finder you can trust.
It’s Wi-Fi connection with your smartphone or tablet gives a stronger connection, bigger range and up to 10X faster data transfer than Bluetooth. This means instant, accurate data on your screen. Plus it makes 10 scans per second, giving it great fish identification accuracy.
The START has been designed to be as easy to use as possible:
At 65g/2.3oz, it’s our lightest ever sonar so there’s no need to worry about line breaks. All our sonars are tested to cast using line from 6lbs / 2.7kg test monofilament up to 20lbs / 9kg test braided line.
The START’s new design makes it super easy to reel in, and features an inbuilt, automatically activated LED for great visibility in all conditions.
Every scan is automatically saved, and can be accessed through the app or online using Lakebook.
Set up couldn’t be simpler with no removable cap, and a custom-built magnetic USB cable for charging that comes with the START.
The START automatically switches on when in water, and off when out of water, helping to conserve battery.
Lighter weight for even easier casting
Cast out using virtually any line and a range of different rods
The START’s new design makes it super easy to reel in, and features an inbuilt, automatically activated LED for great visibility in all conditions.
SPECIFICATIONS
Material
ABS
Compatibility
From iOS 9.0 and Android 4.4 to the latest iOS and Android devices
Sonar Type
Single beam
Frequency (Beam cone)
120 kHz, 40°
Depth Range Max/Min
Max 165ft / 50 m, Min 1.6ft / 0.5 m
Sonar Scan rate
10 scans per second
Operating Temperature
0°C to 40°C/32°F to 104°F
Internal Battery
Lithium Polymer, 3.7V Rechargeable, 850mAh
Power Supply input (for charging battery)
5V DC, 650mA max
Power Adapter (not included in the box, recommended)
Input AC 110V/240V. Output Micro USB A, 5V 450mA
Connection type
Wireless Wi-Fi connection
802.11 b/g 2.412GHz 1channel
802.11 b max TX power +20dBm, sensitivity -91dBm
802.11 g max TX power +17dBm, sensitivity -75dBm
Connection Range
Up to at least 165ft / 50m. Range depends on the OS and smartphone model
Battery Life
Up to 6 hours
Charging Time
2.5 hours
Color
Black and Orange
